JTECH Medical™ Commander Echo Series

Product Group Summary

Commander Echo is a wireless portable evaluation system. It is a modular system providing the ability to purchase only what you need and the option to add on later. Only a single console is required to record data for up to 7 different instruments. The console automatically collects data, stores results, computes statistics and automatically prompts for the next test when testing in a series. The Commander Echo Console also has test selection, the ability to delete unwanted information, and more with a simple control-stick operation. Console Highlights: Large LCD window with easy-to-read character, Automatic test sequencing, Automatically calculates appropriate statistics, Measures in pounds, kilograms, Newtons and degrees, Wireless console is independent of the testing device, allowing the tester to review the data during active testing without influencing patient effort.

Views Of The Products Below

Item # JTECH Medical™ Commander Echo Series List Price
12-0510 console $795.00
JTECH Medical™ Commander Echo - Console only:
Large LCD window with easy-to-read characters. Automatic test sequencing. Stores 20 test with 8 reps per side, and automatically calculates appropriate statistics. Measure in pounds, kilograms and degrees. Bluetooth console is physically independent of the testing device, allowing the tester to review the data during active testing.

Dimensions: 14" x 4.5" x 11.5"

Weight: 1 lbs

UPC: 714905058614

Notice: Typically ships in 1 week.



12-0510 Download Materials

View Catalog Page

Download Image
12-0525 software $400.00
JTECH Medical™ Commander Echo - Software only:
Quickly cerate forms from the data collected on the Commander Echo Console (sold separately). Software interfaces directly with console using Bluetooth. Reports are in color and give space to include information about the patient.

Dimensions: 14" x 4.5" x 11.5"

Weight: 1 lbs

UPC: 714905058768

Notice: Typically ships in 1 week.



12-0525 Download Materials

View Catalog Page

Download Image
12-0511 Dual Inclinometer $1150.00
JTECH Medical™ Commander Echo - Dual Inclinometer:
Stores data for 20 tests with 1-8 repetitions. Measure lordosis, kyphosis and joint ankylosis. Measure agonist/antagonist movements, without stopping or repositioning. Measure ROM using dynamic, auto-rep or static testing.

Dimensions: 14" x 4.5" x 11.5"

Weight: 5 lbs

UPC: 714905058621

Notice: Typically ships in 1 week.




12-0512 Dual Inclinometer with console $1785.00
JTECH Medical™ Commander Echo - Dual Inclinometer with console:
Stores data for 20 tests with 1-8 repetitions. Measure lordosis, kyphosis and joint ankylosis. Measure agonist/antagonist movements, without stopping or repositioning. Measure ROM using dynamic, auto-rep or static testing.

Dimensions: 14" x 4.5" x 11.5"

Weight: 5 lbs

UPC: 714905058638

Notice: Typically ships in 1 week.



12-0512 Download Materials

View Catalog Page

Download Image
12-0513 Manual Muscle Testing Dynamiter $900.00
JTECH Medical™ Commander Echo - Manual Muscle Testing Dynamometer:
Stores up to 20 tests with 1-4 repetitions per side. "axis compensation" circuitry assures accuracy for off-center pad placement. Records peak force and calculates coefficient of variation (cv) and bilateral strength deficits. 150 lb capacity.

Dimensions: 14" x 4.5" x 11.5"

Weight: 7 lbs

UPC: 714905058645

Notice: Typically ships in 1 week.




12-0514 Manual Muscle Testing Dynamiter with console $2100.00
JTECH Medical™ Commander Echo - Manual Muscle Testing Dynamometer with console:
Stores up to 20 tests with 1-4 repetitions per side. "axis compensation" circuitry assures accuracy for off-center pad placement. Records peak force and calculates coefficient of variation (cv) and bilateral strength deficits. 150 lb capacity.

Dimensions: 14" x 4.5" x 11.5"

Weight: 7 lbs

UPC: 714905058652

Notice: Typically ships in 1 week.



12-0514 Download Materials

View Catalog Page

Download Image
Item # JTECH Medical™ Commander Echo Series List Price
12-0515 Grip Dynamometer $1000.00
JTECH Medical™ Commander Echo - Grip Dynamometer:
Stores 20 bilateral tests with 1-8 repetitions per side. Calculates coefficient of variation (CV), right and left average force and bilateral deficit, fatigue and timed fatigue test. Evaluate hand strength and compare results to published data. 200 lb capacity.

Dimensions: 14" x 4.5" x 11.5"

Weight: 6 lbs

UPC: 714905058669

Notice: Typically ships in 1 week.




12-0516 Grip Dynamometer with console $1685.00
JTECH Medical™ Commander Echo - Grip Dynamometer with console:
Stores 20 bilateral tests with 1-8 repetitions per side. Calculates coefficient of variation (CV), right and left average force and bilateral deficit, fatigue and timed fatigue test. Evaluate hand strength and compare results to published data. 200 lb capacity.

Dimensions: 14" x 4.5" x 11.5"

Weight: 6 lbs

UPC: 714905058676

Notice: Typically ships in 1 week.



12-0516 Download Materials

View Catalog Page

Download Image
12-0517 Algometer $1100.00
JTECH Medical™ Commander Echo - Algometer:
Stores 20 tests of any type. Identify small changes in pressure sensitivity. Two pressure measurement tips for applying to large and small muscles of the head and neck.

Dimensions: 14" x 4.5" x 11.5"

Weight: 6 lbs

UPC: 714905058683

Notice: Typically ships in 1 week.




12-0518 Algometer with console $1685.00
JTECH Medical™ Commander Echo - Algometer with console:
Stores 20 tests of any type. Identify small changes in pressure sensitivity. Two pressure measurement tips for applying to large and small muscles of the head and neck.

Dimensions: 14" x 4.5" x 11.5"

Weight: 6 lbs

UPC: 714905058690

Notice: Typically ships in 1 week.



12-0518 Download Materials

View Catalog Page

Download Image
12-0519 Pinch Dynamometer $900.00
JTECH Medical™ Commander Echo - Pinch Dynamometer:
Stores 20 tests of any type. Perform key tip and palmer test. Document bilateral differences, establish baselines and monitor progress. 50 lb capacity.

Dimensions: 14" x 4.5" x 11.5"

Weight: 6 lbs

UPC: 714905058706

Notice: Typically ships in 1 week.




12-0520 Pinch Dynamometer with console $1585.00
JTECH Medical™ Commander Echo - Pinch Dynamometer with console:
Stores 20 tests of any type. Perform key tip and palmer test. Document bilateral differences, establish baselines and monitor progress. 50 lb capacity.

Dimensions: 14" x 4.5" x 11.5"

Weight: 6 lbs

UPC: 714905058713

Notice: Typically ships in 1 week.




Item # JTECH Medical™ Commander Echo Series List Price
12-0521 Goniometer $1050.00
JTECH Medical™ Commander Echo - Goniometer:
Stores 20 bilateral tests with 8 repetitions per side. Compact size is perfect for hand ROM. Extensions prevent large extremity alignment. Calculates coefficient of variation (CV).

Dimensions: 14" x 4.5" x 11.5"

Weight: 5 lbs

UPC: 714905058720

Notice: Typically ships in 1 week.




12-0522 Goniometer with console $1685.00
JTECH Medical™ Commander Echo - Goniometer with console:
Stores 20 bilateral tests with 8 repetitions per side. Compact size is perfect for hand ROM. Extensions prevent large extremity alignment. Calculates coefficient of variation (CV).

Dimensions: 14" x 4.5" x 11.5"

Weight: 5 lbs

UPC: 714905058737

Notice: Typically ships in 1 week.




12-0523 Static Force Gauge Dynamometer $1600.00
JTECH Medical™ Commander Echo - Static Force Gauge Dynamometer:
Stores 20 tests with 8 reps each. Measures push and pull forces and weight. Calculates (CV) for multiple repetitions. Displays maximum force or maximum and average force for each repetition. Time tests from 1-5 seconds, or "untimed" for longer durations. 500 lb capacity.

Dimensions: 14" x 4.5" x 11.5"

Weight: 7 lbs

UPC: 714905058744

Notice: Typically ships in 1 week.




12-0524 Static Force Gauge Dynamometer with console $2185.00
JTECH Medical™ Commander Echo - Static Force Gauge Dynamometer with console:
Stores 20 tests with 8 reps each. Measures push and pull forces and weight. Calculates (CV) for multiple repetitions. Displays maximum force or maximum and average force for each repetition. Time tests from 1-5 seconds, or "untimed" for longer durations. 500 lb capacity.

Dimensions: 14" x 4.5" x 11.5"

Weight: 7 lbs

UPC: 714905058751

Notice: Typically ships in 1 week.




12-0526 Mobile Lift Platform $1050.00
JTECH Medical™ Commander Echo - Mobile Lift Platform:
The Mobile Lift Platform weighs less than 15 pounds but has a 500-pound lift capacity. This portable platform includes an easy to adjust strap to accommodate height differences, a connector for the Force Gauge and an integrated grid pattern for fast, accurate foot placement. This Mobile Lifting System is a compact, well-designed static lifting system that is great for FCEs, Jobsite analysis and Pre-placement Screens. The handle can be moved up and away from the body for High-Far and High-Near Lifts.

Dimensions: 30" x 5.6" x 15"

Weight: 16 lbs

UPC: 714905091130

Notice: Typically ships in 1 week.



12-0526 Download Materials

Download Image
